Investment Casting



Investment Casting
Investment casting is an industrial process based on and also called lost-wax casting, one of the oldest known metal-forming techniques. The castings allow the production of components with accuracy, repeatability, versatility and integrity in a variety of metals and high-performance alloys.

The process is generally used for small castings, but has been used to produce complete aircraft door frames, steel castings of up to 300 kg (660 lbs) and aluminium castings of up to 30 kg (66 lbs). It is generally more expensive per unit than die casting or sand casting, but has lower equipment costs. It can produce complicated shapes that would be difficult or impossible with die casting, yet like that process, it requires little surface finishing and only minor machining.


Product Scope
Material: Carbon steel, Stainless steel, Alloy steel, super alloy steel. Nickel-based cast super alloy, Model metal, Cobalt-based cast Super alloy or according to customers’ requirements.
The scope of weight: 0.02kgs-150kgs
The precision of dimension: CT5-CT9
Output per month: 40Tons
Surface finish: Shot blasting, Galvanizing, Polishing

Application
Automotive, Marine, Mine, Turbine blades, Armament parts, Pipe fittings, Lock parts, Hand tools etc.
